APRICOT 600 Liftmounted sprayer features

Optional unit
Code: HLM600F603+100574+100617
Dimensions: LXWXH (cm):127x132x134
Weight: 127.9 Kg

Base unit
Code: HLM600F
Dimensions: LXWXH(cm):127x86x134
Weight: 100.9 Kg

Liftmounted type sprayer, 600 L fiberglass tank with external level indicator with graduated scale, total drainage tank, 3 ways ball valve, external suction filter, agitation via return hose, 2 x 15m rubber hose Ø10 mm – 40 bar, 2 x 30 cm spray gun, A2 protected cardan shaft.

Code	Pump	Delivery L/min	Pressure bar	Regulator	Weight Kg
HLM600F601	Comet APS 51	50.7	40	Polaris 2 outlet 40 bar	17.6
HLM600F602	Comet YA 65	55	50	GCP 3 outlet 50 bar	18.6
HLM600F603	Udor KAPPA 53	55	40	DL 2 outlet 40 bar	12
HLM600F604	Udor GAMMA 62	68	50	ZX 3 outlet 50 bar	23.5

Legend Code

H	Hazan
LM	Liftmounted
600	Tank capacity (Lt)
F	Fiberglass Tank
601	Pump – Regulator - type

Optional Pumps

Comet APS 51 - 3 diaphragms	Comet YA 65 – 3 pistons	Udor KAPPA 53 – 3 diaphragms	Udor GAMMA 62 – 3 pistons
Power: 5.2 HP R.P.M: 550 Weight: 16.4 Kg	Power: 7.7 HP R.P.M: 650 Weight: 16 Kg	Power: 5.2 HP R.P.M: 550 Weight: 11 Kg	Power: 8.6 HP R.P.M: 600 Weight: 21 Kg

Optional Regulator

Regulator Polaris	Regulator GCP	Regulator DL	Regulator ZX
Pressure: 40 bar Max Delivery: 50 L/min Weight: 1.2 Kg	Pressure: 50 bar Max Delivery: 100 L/min Weight: 2.6 Kg	Pressure: 40 bar Max Delivery: 100 L/min Weight: 1 Kg	Pressure: 50 bar Max Delivery: 120 L/min Weight: 2.5 Kg

Optional Extras

1 or 2 LM hose reel Garden Mini 50 kit	Rubber hose Ø10mm 40 bar L50m
Code: 100574 Dimensions LXWXH (cm): 40x48x48 Weight: 6.5 Kg	Code: 100617 Dimensions LXWXH (cm): 40x17x40 Weight: 8.5 Kg

Features are subject to change without prior notice.
