CARAMBOLA 1200 Trailed mistblower sprayer features
Carambola 1200-Optional Unit


Optional unit
Code: HTM1200F1202
Dimensions: LXWXH (cm): 370X146X142
Weight: 530 Kg

Base unit
Code: HTM1200F
Dimensions: LXWXH(cm): 370X146x142
Weight: 499.4Kg


Trailed  mistblower type sprayer, 1200 L fiberglass tank with external level indicator with graduated scale, total drainage tank,  3 ways ball valve, external suction filter and pressure line filter for nozzles, agitation via hydraulic agitator,  2 – speed gear box + neutral point, anti – drip double sided brass nozzles, air deflector, fan diameter 820 mm, A6 protected cardan shaft.


Code Pump Delivery L/min Pressure bar Regulator Weight Kg
HTM1200F1201 Comet APS 121 115 50 Alfa 2 outlet 50 bar 40.6
HTM1200F1202 Comet YA 130 104 50 Alfa 2 outlet 50 bar 30.6
HTM1200F1203 Udor KAPPA 120 133 50 UHP 2 outlet 50 bar 44.6
HTM1200F1204 Udor GAMMA 105 109 60 UHP 2 outlet 50 bar 40.6


Legend Code


H Hazan
TM Trailed mistblower
1200 Tank capacity (Lt)
F Fiberglass Tank
1201 Pump – Regulator – type


Optional Pumps

Comet APS 121 - 3 diaphragms

Comet YA 130 – 6 pistons

Udor KAPPA 120 – 4 diaphragms

Udor GAMMA 105 – 6 pistons

Power: 13.1 HP
R.P.M: 550
Weight: 38 Kg

Power: 13.1 HP
R.P.M: 650
Weight: 28 Kg

Power: 16 HP
R.P.M: 550
Weight: 42 Kg

Power: 16.6 HP
R.P.M: 600
Weight: 38 Kg

Optional Regulator

Regulator Alfa

Regulator UHP

Pressure: 50 bar
Max Delivery: 180 L/min
Weight: 2.9  Kg

Pressure: 50 bar
Max Delivery: 170 L/min
Weight: 2.6 Kg



Features are subject to change without prior notice.
