BLUEBERRY 600 Pick - Up sprayer features

Optional unit
Code: HPU600F601
Dimensions: LXWXH (cm): 140X86X134
Weight: 152 Kg

Base unit
Code: HPU600F
Dimensions: LXWXH(cm): 140X86X134
Weight:122.6Kg

Pick - Up type sprayer with gear driven system, 600 L fiberglass tank with external level indicator with graduated scale, total drainage tank, 3 ways ball valve, external suction filter, agitation via return hose, hose reel Garden Mini 50, 50m rubber hose Ø10 mm – 40 bar, 30 cm spray gun .

Code	Pump	Delivery L/min	Pressure bar	Regulator	Engine Specifications	Weight Kg
HPU600F601	Comet APS 31	25	40	Gemini 2 outlet 40 bar	B & S Intek I/C 6.0 HP	29.4
HPU600F602	Comet APS 31	25	40	Gemini 2 outlet 40 bar	Kohler Courage 6.5 HP	29.4
HPU600F603	Comet APS 31	25	40	Gemini 2 outlet 40 bar	Loncin G200F 6.5 HP	29.4
HPU600F604	Comet APS 31	25	40	Gemini 2 outlet 40 bar	Electrical Single-Phase 230V 50 Hz 3 HP	31
HPU600F605	Comet APS 31	25	40	Gemini 2 outlet 40 bar	Electrical Three-Phase 400V 50 Hz 3 HP	31
HPU600F606	Udor KAPPA 33	33	40	DL 2 outlet 40 bar	B & S Intek I/C 6.0 HP	30
HPU600F607	Udor KAPPA 33	33	40	DL 2 outlet 40 bar	Kohler Courage 6.5 HP	30
HPU600F608	Udor KAPPA 33	33	40	DL 2 outlet 40 bar	Loncin G200F 6.5 HP	30
HPU600F609	Udor KAPPA 33	33	40	DL 2 outlet 40 bar	Electrical Single-Phase 230V 50 Hz 3 HP	31.5
HPU600F610	Udor KAPPA 33	33	40	DL 2 outlet 40 bar	Electrical Three-Phase 400V 50 Hz 3 HP	31.5

Legend Code

H	Hazan
PU	Pick- Up
600	Tank capacity (Lt)
F	Fiberglass Tank
601	Pump – Regulator - Engine type

Optional Engines

B & S Intek I/C 6.0 HP	Kohler Courage 6.5 HP	Loncin G200F 6.5 HP	Electrical Single Phase 230V 50 Hz 3 HP
Engine Displacement: 205 cc Fuel Type: Gasoline Dry Weight: 16 Kg	Engine Displacement: 196 cc Fuel Type: Gasoline Dry Weight: 16 Kg	Engine Displacement: 196 cc Fuel Type: Gasoline Dry Weight: 16 Kg	KW: 2.2 R.P.M: 2810 Weight: 17.5 Kg
Electrical Three Phase 400V 50 Hz 3 HP
KW: 2.2 R.P.M: 2850 Weight: 17.5 Kg

Optional Pumps & Regulators

Comet APS 31 - 3 diaphragms	Regulator Gemini	Udor KAPPA 33 – 3 diaphragms	Regulator DL
Power: 2.7 HP R.P.M: 550 Weight: 10 Kg	Pressure: 40 bar Max Delivery: 50 L/min Weight: 0.9 Kg	Power: 3.0 HP R.P.M: 550 Weight: 11 Kg	Pressure: 40 bar Max Delivery: 100 L/min Weight: 1 Kg

Optional Extras

Hose reel Garden Mini 50	Rubber hose Ø10mm 40 bar L50m
Code: 100699 Dimensions LXWXH (cm): 40x48x48 Weight: 5 Kg	Code: 100617 Dimensions LXWXH (cm): 40x17x40 Weight: 8.5 Kg

Features are subject to change without prior notice.
